First appeared in Radio Shack Computer Catalog number 1 in 1977. It was originally known as the TRS-80 Micro Computer, before the Model II was released.
Microprocessor: Advanced Z-80 8-bit processor.
Keyboard: Integrated ASCII, 53-key professional-type.
Video Display: Memory mapped, all graphics and alphanumerics controlled by BASIC commands. Cursor control. Automatic scrolling.
- Text: 16 lines of 64 characters, also software selectable to 32 characters per line.
- Graphics: 128 horizontal by 48 vertical. Graphics and text can be interspersed in any manner by software.
Memory: Includes 4K Read-Only-Memory (ROM), 4K dynamic Read/Write Memory (RAM). Internally expandable in the computer case to 12K ROM and 16K RAM. Total memory capability of 62K.
Input/Output: Computer-conrolled cassette interface. Expansion port for additional memory and peripherals. Keyboard built-in.
Electrical: U.L listed for 120 volts AC, 60Hz.
Radio Shack Level-I BASIC in ROM.
Level 1 Features: standard BASIC statements; floating point arithmetic; numeric, array, and string variables; video graphics commands; cassette save and load commands.
Commands: NEW, LIST, RUN, CONTinue, REMark, LET, FOR-NEXT-STEP, GOSUB-RETURN, STOP. END, GOTO, IF-THEN, INPUT, ON...GOTO, ON...GOSUB, PRINT, CSAVE CLOAD, DATA, READ, RESTORE.
Functions: MEM, TAB, INT, ABS, RND, +, -, *(multiply), /(divide), <, >, =.
Special Commands (Including graphics): CLS (clear screen), SET (x,y), RESET (x,y), POINT (x,y), formatted PRINT, Array and string capability. Data storage and retrieval.
Video Display: 12" diagonal screen. 16.5x13.5x12". U.L. listed.
CTR-41 Data Cassette: Battery or AC operation. U.L. listed.
26-2101 User's Manual For Level 1
TRS-80 Technical Manual (For Radio Shack Service Centers)
26-2103 TRS-80 Micro Computer Technical Reference Handbook
26-1201 Video Display
14-0841 Realistic Portable Cassette Player CTR-41
|26-1701||Math I||Level I|
|26-1702||Algebra I||Level I|
|26-1802||Quick Watson!||Level I or II|
|26-1805||Games Pack I||Level I|
|26-1901||Microchess||Level I or II|
|26-1902||Micro Music||Level I or II|
|29-1903||Micro Movie||Level I or II|
|26-1904||Micro Marquee||Level I or II|
|26-2003||Level I BASIC Course||Level I|
